2.精确度 : ±1%
3.两组温度测量及显示(T1或T2)
4.取样时间0.4秒
5.感测棒型式:TYPE K 热电偶测棒
6.Size：131 X 70 X 25mm
般規格：
| Display | 3 1/2 digits with annuciator, 15 mm ( 0.5&quo ) LCD |
| Sensor Type | Thermocouple K |
| ( NiCr- NiAl), Optional | |
| Measurement | Two channel input ( T1, T2 ) |
| Range Resolution | TM-914C: -40℃ to 1200℃ &time 1℃ |
| TM-914F: -40℉ to 1382℉ &time 1℉ | |
| Sampling Time | Approx. 0.4 second |
| Power Supply | DC 9V battery, 006P, MN1604 or equivalent |
| Power Current | Approx. DC 1.8 mA |
| Dimension | 108 &time 73 &time 23 mm ( 4.3 &time 2.9 &time 1.4 inch ) |
| Weight | 140 g/0.31 LB |
| Accessory | Operation Manual.................................. 1PC |
|
精 確 度 ( 23&plusm5℃ )
|
|
| TM-914C: | &nbs |
| 0 to 750℃:&plusm(1% + 1℃ ) 750 to 1000℃: typ. - ( 2% + 1℃ ) 1000 to 1200℃: typ. - ( 4% + 3℃ ) 0 to -20℃: typ.&plusm2℃ * typ. : Typically |
32 to 1382℉:&plusm( 1% + 2℉ ) 1382 to 1832℉: typ. - ( 2% + 2℉ ) 1832 to 2000℉: typ. - ( 2% + 4℉ ) 32 to -4℉: typ.&plusm 4℉ -4 to -40℉: typ. &plusm 6℉ * typ. : Typically |
選購附件：
| Temperature Probe |
Model: TP-01 | -40℃ to 250℃ continuous (3000℃ short-term). Applications: Ultra fast response naked-bead therm ocouple wire, suitable for many general purpose application |
| Model: TP-02A | -50℃ to 900℃ (-50℉ to 1650℉ ). Dimension: 10 cm tube, 3.2 mm Dia. Penetration &am Immersion applications |
|
| Model: TP-03 | -50℃ to 1200℃ (-50℉ to 2200℉ ). Dimension: 10 cm tube, 8 mm Dia. Applications: High temperature, Penetration &am Immersion |
|
| Model: TP-04A | -50℃ to 400℃ (-50℉ to 752℉ ). Dimension: Temp. sensing head-15 mm Dia. Probe length-120 mm. Applications: Precision surface temp. measurement usage |
|
| Carrying case | Model: CA-04 | Soft carrying case |
| Holster | Model: HS-02 | High quality rubber protective holster |
